6-3 w/ Ground Tray Cable - THHN/PVC

Parent SKU :  TCTHN6-3

SKU :  TCTHN6-3-250

VNTC TYPE TC-ER. SUNIGHT RESISTANT & DIRECT BURIAL RATED.
Download Spec Sheet
6-3C Tray Cable with Ground, Copper THHN/THWN-2 PVC 600V Type TC-ER, Sunlight Resistant and Direct Burial rated industrial power wire.
Wire Size 6 AWG
Conductor Type Stranded
Outer Diameter 0.69 in.
Conductor Count 3
Voltage Rating 600V
Ampacity Rating 75
Direct Burial Yes
Download Spec Sheet

Product Details

Product Details
APPLICATION:
Tray Cable UL Type TC / TC-ER with THHN/THWN-2 Insulation is primarily used for power, control, signal, communication, and lighting circuits in commercial and industrial environments. Suitable for installations in cable trays, supported by messenger wire in open air, raceways, channels, conduits and ducts, direct burial applications not exceeding 600 volts.

CONDUCTORS:
Soft or annealed bare copper per ASTM B3 and B8 compressed in Class B stranding.

COLOR CODE:
3 black conductors with printed white numbers 1, 2 and 3.

GROUND SIZE:
8 AWG

INSULATION:
THHN/THWN-2 Heat and moisture resistant Polyvinylchloride (PVC) with a Nylon jacket, per UL 83.

ASSEMBLY:
Conductors are cabled together with or without fillers as required to form a round, compact cable core with a binder tape.

AMP RATING:
@ 90°C - 75 Amps



All values are nominal and subject to correction *Ampacities for not more than three current-carrying conductors in raceway, cable, or earth (directly buried) at ambient temperature of 30°C per NEC table 310.16. Refer to the NEC for deratings due to different conditions.

Full Specifications

Full Specifications
Download Spec Sheet

Physical Specifications

Wire Size (AWG/MCM) 6 AWG
Conductor Material Copper
Conductor Type Stranded
Strand Count 7
Outer Diameter (OD) (in/mm) 0.69 in.
Jacket Type PVC with a Nylon Jacket
Conductor Count 3
Shield Unshielded
Insulation Type (PVC) Polyvinyl Chloride
UL Listing Numbers Type TC/TC-ER, UL 83, UL 1277, UL 1685

Technical Specifications

Voltage Rating 600V
Ampacity Rating 75
Direct Burial Rating Yes
Submersible No
Sunlight Resistance Rating Yes
Temperature Rating 90ºC
Standards UL 83, UL1277
UL 1685 Vertical-Tray Fire-Propagation and Smoke-Release Test
Approved for Class 1 or 2, Division 2 industrial hazardous locations per NEC
ICEA S-95-658
UL Listed as Type TC or TC-ER, Sunlight Resistant, Direct Burial
UL Listed to IEEE1202 and CSA FT4 70, 000 BTU Flame Test
ASTM B3, ASTM B8
NEC Article 336, Article 501, Article 725 for class 1 circuits
Miscellaneous Information All values are nominal and subject to correction *Ampacities for not more than three current-carrying conductors in raceway, cable, or earth (directly buried) at ambient temperature of 30°C per NEC table 310.16. Refer to the NEC for deratings due to different conditions.
Other Certifications UL 66, UL 83, UL1277, UL 1685

Usage & Installation

Primary ApplicationsIndustrial Power and Control Systems, Building Automation and Energy Management, Utility and Substation Wiring, Instrumentation and Process Control, Cable Tray Installations, Outdoor and Direct Burial.
Common Uses
  • Control circuits for motors
  • machinery
  • automated equipment
  • connecting sensors
  • actuators
  • and controllers for HVAC
  • lighting
  • and security systems.

Packaging & Dimensions:

Weight per Foot 0.424 lb
