1 AWG Stranded Tinned Bare Copper Wire, Soft Drawn, 7 Strand

Parent SKU :  BCTSTR1

SKU :  BCTSTR1-250

UNINSULATED ELECTRICAL WIRE COMMONLY USED FOR GROUNDING ELECTRICAL SYSTEMS.
Download Spec Sheet
Wire Size 1 AWG
Conductor Material Tinned Copper
Strand Count 7
Outer Diameter 0.328 in.
Ampacity Rating 265
Weight per Foot 0.2584 lb
Download Spec Sheet

Product Details

Product Details
APPLICATION:
Stranded Tinned Copper Wire is an uninsulated electrical conductor made up of multiple fine strands of copper twisted together. A soft drawn conductor is either hot dipped or electroplated with tin. This process significantly improves corrosion resistance. It contains no insulating jacket or protective coating, with its key characteristics coming from its flexibility, high conductivity, and resistance to corrosion.

CONDUCTOR:
Stranded tin coated copper conductors available in soft temper only.

NUMBER OF STRANDS:
7

RATED STRENGTH
2,552 lbs.

DC RESISTANCE AT 20ºC
0.12520 Ohms/1000 ft.

AMP RATING:
265 Amps



All values are nominal and subject to correction. *Ampacity based on 75°C conductor temperature; 25°C ambient temperature; 2ft./sec. wind in sun.

Full Specifications

Full Specifications
Download Spec Sheet

Physical Specifications

Wire Size (AWG/MCM) 1 AWG
Conductor Material Tinned Copper
Conductor Type Stranded
Strand Count 7
Outer Diameter (OD) (in/mm) 0.328 in.
Conductor Count 1
Shield Unshielded

Technical Specifications

Ampacity Rating 265
Direct Burial Rating Yes
Submersible No
Sunlight Resistance Rating Yes
Standards ASTM B-1 Hard-drawn copper wire
ASTM B-2 Medium-hard drawn copper wire
ASTM B-3 Soft or annealed copper wire
ASTM B-8 Concentric-lay stranded copper conductors: hard, medium-hard, or soft
ASTM B-33 Tinned soft or annealed copper wire
ASTM B-258
Federal Sepc QQ-W-364
Miscellaneous Information All values are nominal and subject to correction. *Ampacity based on 75ºC conductor temperature; 25ºC ambient temperature; 2ft./sec. wind in sun.

Usage & Installation

Primary ApplicationsGrounding Systems, Overhead Power Distribution, Ground Wire for Lightning Protection, Bonding Applications, Messenger and Support Wires
Common Uses
  • Used in both commercial and residential grounding systems
  • as well as for grounding utility equipment and substations.

Packaging & Dimensions:

Weight per Foot 0.2584 lb
