1/0 Stranded Bare Copper Wire, Soft Drawn,19 Strand

Parent SKU :  BCSTR1/0-19

SKU :  BCSTR1/0-19-250

UNINSULATED ELECTRICAL WIRE COMMONLY USED FOR GROUNDING ELECTRICAL SYSTEMS.
Download Spec Sheet
Wire Size 1/0
Conductor Material Copper
Strand Count 1900-01-18
Outer Diameter 0.373 in.
Ampacity Rating 310
Weight per Foot 0.3258 lb
Download Spec Sheet

Product Details

Product Details
APPLICATION:
Stranded Bare Copper Wire is an uninsulated electrical conductor made up of multiple fine strands of copper twisted together. It contains no insulating jacket or protective coating, with its key characteristics coming from its flexibility, high conductivity, and resistance to corrosion.

CONDUCTOR:
Concentric-lay stranded bare soft drawn copper conductors.

NUMBER OF STRANDS:
19

RATED STRENGTH
3,221 lbs.

DC RESISTANCE AT 20ºC
0.10020 Ohms/1000 ft.

AMP RATING:
310 Amps



All values are nominal and subject to correction. *Ampacity based on 75°C conductor temperature; 25°C ambient temperature; 2ft./sec. wind in sun.

Full Specifications

Full Specifications
Download Spec Sheet

Physical Specifications

Wire Size (AWG/MCM) 1/0
Conductor Material Copper
Conductor Type Stranded
Strand Count 1900-01-18
Outer Diameter (OD) (in/mm) 0.373 in.
Conductor Count 1
Shield Unshielded

Technical Specifications

Ampacity Rating 310
Direct Burial Rating Yes
Submersible No
Sunlight Resistance Rating Yes
Standards ASTM B-1 Hard-drawn copper wire
ASTM B-2 Medium-hard drawn copper wire
ASTM B-3 Soft or annealed copper wire
ASTM B-8 Concentric-lay stranded copper conductors: hard, medium-hard, or soft
ASTM B-33 Tinned soft or annealed copper wire
ASTM B-258
Federal Sepc QQ-W-365
Miscellaneous Information All values are nominal and subject to correction. *Ampacity based on 75ºC conductor temperature; 25ºC ambient temperature; 2ft./sec. wind in sun.

Usage & Installation

Primary ApplicationsGrounding Systems, Overhead Power Distribution, Ground Wire for Lightning Protection, Bonding Applications, Messenger and Support Wires
Common Uses
  • Used in both commercial and residential grounding systems
  • as well as for grounding utility equipment and substations.

Packaging & Dimensions:

Weight per Foot 0.3258 lb
