Prent SKU:BRE8K-3URD
SKU:BRE8K-3URD-100
| Wire Size (AWG/MCM) | 1/0 |
| Conductor Material | Aluminum |
| Conductor Type | Stranded |
| Strand Count | 19 |
| Outer Diameter (OD) (in/mm) | 1.11 in. / 28.19 mm |
| Jacket Type | XLPE |
| Conductor Count | 3 |
| Shield | Unshielded |
| Insulation Type | (XLPE) Cross-Linked Polyethylene |
| Voltage Rating | 600V |
| Ampacity Rating | 215 |
| Direct Burial Rating | Yes |
| Submersible | No |
| Flexibility Rating | Low |
| Sunlight Resistance Rating | Yes |
| Temperature Rating | 90ºC |
| Standards | UL 44 Thermoset-Insulated Wires and Cables UL 854 Service-Entrance Cables ASTM B800 8000 Series Aluminum Alloy Wire for electrical Purposes-Annealed and Intermediate Tempers ASTM B801 Concentric-Lay-Stranded Conductors of 8000 Series Aluminum Alloy for Subsequent Covering or Insulation ASTM B901 Compressed Round Stranded Aluminum Conductors Using Single Input Wire Construction ICEA S-105-692 600 Volt Single Layer Thermoset Insulated Utility Underground Distribution Cables Federal Specification A-A-59544A Cable and Wire, Electrical RUS Accepted |
| Miscellaneous Information | All values are nominal and subject to correction *Ampacity: 90°C conductor temperature, 20°C ambient temperature, RHO 90, 100% load factor. Neutral carries unbalanced load only. |
| Primary Applications | Underground Secondary Power Distribution |
| Common Uses |
|
| Weight per Foot | 0.406 lb |
